InHand Networks - VG710-FS59
Multi-Network Vehicle Gateway
Listprice:
£530.70*
Dealer price - Login
10 pieces available, delivery time: 5 - 7 working days
Prices for larger quantities please inquire.
Tel: +44 (0) 1276 819333 or e-mail: shop@s-connect.ltd.uk
Tel: +44 (0) 1276 819333 or e-mail: shop@s-connect.ltd.uk
Manufacturer part number:
VG710-FS59
Our article number:
810041
Questions? We will be happy to advise you! → Contact form
Product information "InHand Networks - VG710-FS59"
High-performance Vehicle Network, Powerful Data Processing, Flexible Development
The InVehicle G710 is a new vehicle LTE gateway developed specially for the Internet of Vehicles (IoV). It provides high-speed and secure connectivity for mission critical applications in a wide range of scenarios, such as police cars, heavy equipment, ambulances, and logistics. Equipped with cloud-based remote fleet management platform, it offers ubiquitous networking and uninterrupted monitoring for logistics management, asset tracking, mobile office and public security.
Scope of delivery: InHand Networks - VG710-FS59
The InVehicle G710 is a new vehicle LTE gateway developed specially for the Internet of Vehicles (IoV). It provides high-speed and secure connectivity for mission critical applications in a wide range of scenarios, such as police cars, heavy equipment, ambulances, and logistics. Equipped with cloud-based remote fleet management platform, it offers ubiquitous networking and uninterrupted monitoring for logistics management, asset tracking, mobile office and public security.
Scope of delivery: InHand Networks - VG710-FS59
| Certifications: | E-Mark |
|---|---|
| Connection: | Digitale I/O, Ethernet Port, Serial Ports RS232, RS422/485 |
| Fieldbus options: | CAN-BUS |
| Options: | Bluetooth, LTE, WiFi |
| Power Supply: | 12V DC, 24 - 36V DC |
| Temperature Range: | Standard Temperature Range |
| Wireless Option: | Bluetooth, GNSS / GPS / Glonass / Beidou, WiFi |
Features
High-speed Vehicle Networking with Multiple Interfaces
With vehicle grade hardware, the VG710 offers high-speed vehicle networking, LTE CAT6 high-speed WAN and Gigabit Ethernet, providing vehicles, devices and passengers with fast, reliable and secure Internet connectivity.
Featuring extensive interfaces such as cellular, Ethernet, Wi-Fi, CAN, I/O, serial ports, Bluetooth and GNSS, the VG710 delivers appropriate connectivity solutions and enables efficient retrofit on existing vehicles.
Real-time Monitoring of Vehicle Status
Integrating OBD-II and J1939, the VG710 enables real-time vehicle diagnostics. The embedded GNSS offers uninterrupted precise positioning, with remote analysis software monitoring dangerous driving behavior, thus ensuring driving safety.
Uninterrupted High-accuracy Vehicle Location
The 72-channel high-accuracy and high-sensitivity GNSS positioning system, which includes GPS, GLONASS, Galileo and Beidou, is ideal for global deployment, delivering real-time location information of vehicles. The inertial navigation system offers excellent positioning precision when GNSS signal is unavailable.
Open, Easy-to-use Development Platform for Custom Applications
Powerful edge computing capabilities facilitate the development of custom applications. The remote fleet management platform is easy for secondary development by third-party software developers. With an open cloud ecosystem that supports Microsoft Azure and AWS, the VG710 offers more options for application developers. It supports Node-RED low code edge computing solutions.
Purpose Designed for Vehicles
The vehicle grade processor chip ensures constant and reliable operation in harsh environments. Designed for IP64 for resistance to dust and water ingress, the VG710 survives water splash, dust, shock, vibration, humidity and extreme temperatures. Following technical specifications for vehicle-mounted devices, the VG710 proves secure and reliable for vehicle environments.
Major IoT Cloud Services Supported
The accomplished secondary development platform offers key system resources, facilitating development and deployment of custom applications. Integrating Python SDK and Docker, the VG710 enables users to quickly build applications based on major clouds such as Azure IoT Edge. With support for FlexAPI that works for third-party platforms, the VG710 embraces the open IoT ecosystem with more choices for application developers. It supports Device Manager for centralized management with greater efficiency.
High-speed Vehicle Networking with Multiple Interfaces
With vehicle grade hardware, the VG710 offers high-speed vehicle networking, LTE CAT6 high-speed WAN and Gigabit Ethernet, providing vehicles, devices and passengers with fast, reliable and secure Internet connectivity.
Featuring extensive interfaces such as cellular, Ethernet, Wi-Fi, CAN, I/O, serial ports, Bluetooth and GNSS, the VG710 delivers appropriate connectivity solutions and enables efficient retrofit on existing vehicles.
Real-time Monitoring of Vehicle Status
Integrating OBD-II and J1939, the VG710 enables real-time vehicle diagnostics. The embedded GNSS offers uninterrupted precise positioning, with remote analysis software monitoring dangerous driving behavior, thus ensuring driving safety.
Uninterrupted High-accuracy Vehicle Location
The 72-channel high-accuracy and high-sensitivity GNSS positioning system, which includes GPS, GLONASS, Galileo and Beidou, is ideal for global deployment, delivering real-time location information of vehicles. The inertial navigation system offers excellent positioning precision when GNSS signal is unavailable.
Open, Easy-to-use Development Platform for Custom Applications
Powerful edge computing capabilities facilitate the development of custom applications. The remote fleet management platform is easy for secondary development by third-party software developers. With an open cloud ecosystem that supports Microsoft Azure and AWS, the VG710 offers more options for application developers. It supports Node-RED low code edge computing solutions.
Purpose Designed for Vehicles
The vehicle grade processor chip ensures constant and reliable operation in harsh environments. Designed for IP64 for resistance to dust and water ingress, the VG710 survives water splash, dust, shock, vibration, humidity and extreme temperatures. Following technical specifications for vehicle-mounted devices, the VG710 proves secure and reliable for vehicle environments.
Major IoT Cloud Services Supported
The accomplished secondary development platform offers key system resources, facilitating development and deployment of custom applications. Integrating Python SDK and Docker, the VG710 enables users to quickly build applications based on major clouds such as Azure IoT Edge. With support for FlexAPI that works for third-party platforms, the VG710 embraces the open IoT ecosystem with more choices for application developers. It supports Device Manager for centralized management with greater efficiency.
Technical details
InVehicle G710 Software Specifications
Item: InVehicle G710
Network Connection
Network Access: APN, VPDN
Access Authentication: CHAP/PAP/MS-CHAP/MS-CHAP V2
LAN Protocol: ARP, Ethernet
Network Protocols
IP Applications: IPv6, Ping, Traceroute, DHCP server/relay/client, DNS relay, DDNS, Telnet, SSH, HTTP, HTTPS, TFTP, FTP, SFTP, Portal
IP Routing: Static routing, RIP, OSPF, BGP, IGMP Proxy
Network Security
Firewall: SPI, DoS attack defense, multicast/Ping probe filter, ACLs; Supports NAT, PAT, DMZ, port mapping, virtual server
User Level: 2 levels: administrator; read-only user
AAA: Local authentication, Radius, Tacacs+, LDAP
CA Certificate: PEM, PKCS12, SCEP
VPN: IPsec VPN, L2TP, PPTP, GRE, OPENVPN, CA
Reliability
Backup: Floating routing, VRRP, interface backup
Link Detection: Sends heartbeat packet to detect, auto redial when disconnected
Watchdog: Runs self-detection and auto-repairing of device faults
Offline Storage: Built-in cache, records key data when network unavailable
Ports
VLAN Partition: Supported
Port Mirroring: Supported
WLAN
Protocol: IEEE 802.11 ac/a/b/g/n
Security: Shared key, WPA/WPA2 authentication, WEP/TKIP/AES encryption
Network Management
Configuration: Local or remote HTTP, HTTPS, Telnet, SSH
Upgrade: Local or remote WEB, DM, TFTP, FTP, SFTP server
AAA: Local/Radius/TACACS+
Network Diagnostic: Ping, Traceroute, Sniffer (network packet capturing tool)
Edge Computing Framework
Edge Computing Platform: An edge computing platform integrating network, computing, storage and applications
Edge Computing Engine: Python & Docker
SDK: Python 3 SDK, Docker SDK and Azure IoT Edge SDK
IDE: Visual Studio Code
IoT Architecture: Supports MQTT, DDS, AMQP, XMPP, JMS, REST, CoAP
3rd Party Cloud: MS Azure, SmartFleet and development APIs for other third-party platforms
Docker Images: Node-RED, Ubuntu, Docker for ARM 32, etc.
Application Services
Fleet Management Cloud: InHand Smartfleet cloud platform: task allocation, route planning, vehicle tracking, real-time messaging, geofencing, batch firmware upgrade, batch configuration backup, application upgrade
Vehicle Telemetry: Rich interfaces for vehicle telemetry and asset tracking devices
Event Alarm: Customizable event alarms: digital input, network, service status, power supply, temperature, voltage, etc.
Message Push: SMS, Email, App, device digital output
InVehicle G710 Hardware Specifications
Item: InVehicle G710
Hardware Platform
CPU: ARM Cortex A7
RAM: 1GB/512MB DDR3
FLASH: 8GB eMMC
Main Frequency: 717MHz
Satellite Navigation
GNSS Receiver: GPS, GLONASS, Galileo, Beidou
Built-in Sensor: Inertial navigation sensor (accelerometer and gyroscope)
Position Deviation: 1.5m (With SBAS)，2.5m (Autonomous)
Tracking Sensitivity: -160dBm
Location Update Rate: MAX 10Hz
Interface
Cellular: LTE CAT6/ CAT4
Ethernet: 4*10/100/1000Mbps RJ45 interface
Serial Port: RS232 serial (DB-9)
USB Port: USB2.0 ，Micro-B (Read-write: MAX 480Mbps)
MircoSD: Micro SD Card (up to 32GB, 20MB/s)
Bluetooth: Bluetooth 4.1
Antenna: SMA-K: Cellular, GNSS, Diversity; RPSMA-K: 2*Wi-Fi, Bluetooth
Indicator: System, LTE, Signal, GNSS, Wi-Fi 2.4G, Wi-Fi 5G, U1, U2
Wi-Fi
Frequency: 2.4G / 5GHz dual-band
Protocol: Wi-Fi 5
Maximum Output: 2.4g:17dBm 5g:17dBm
Working Mode: AP /Client
Automotive Interface
DI: 6*digital input / 6 channels multiplexing, configurable
AI: 6*analog input / 6 channels multiplexing, configurable
DO: 4*digital output
Diagnostic Interface: CanBus
RS485: RS485 serial (A+, B-, GND)
Other: 1 WIRE (driver ID/temperature sense)
Power Supply
Pin Definition: V+, V-, ignition signal, NC (4 pins)
Input Voltage: 9-36VDC [configurable to 7-36VDC]
Protection: Built-in voltage transient protection, with delayed ignition induction
Standby Power: 0.006W - monitors ignition signal only; system starts on ignition
Operating Power: 12.00W - average when RF module not running at full load
Peak Power: 18.20W - peak value when RF module running at full load
Mechanical
Installation: Wall-mounting
Protection Rating: IP64
SIM Card Slot: Dual SIM
SIM Card Spec: 2FF
Cooling: Radiation cooling
Housing: Die-cast aluminum
Dimensions (mm): 186x128.5x48
Real-time Clock: Supported
Weight: 775g
Environment
Operating Temperature: -30°C ~ +70°C, -22°F ~ +158°F
Humidity: 95％RH @ 60°C
Storage Temperature: -40°C ~ +85°C / -40°F ~ +185°F
Vehicle
EMC: Level 3 (EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-18)
Rail Standard: EN50155, EN50121, EN61373, EN45545
Physical
Shock: IEC60068-2-27
Vibration: IEC60068-2-6
Fall: IEC60068-2-32
Certification: CE, FCC, IC, PTCRB, AT&T, E-Mark, RoHS
